CPU
º Onboard Intel® Celeron 847/807/1037U processors
º Solid Capacitor for CPU side
CHIPSET
º Intel® NM70 Express Chipset
GRAPHICS
º Supports DirectX® 10.1
MEMORY
º Supports DDR3 1333/1066 non-ECC, Un-buffered
SDRAM Memory
º 2 X 240-pin DDR3 DIMM socket
EXPANSION SLOT
º 1 X PCI Express X16 Gen 2.0 slot(s)
Storage
º Support by IntelNM70 Express Chipset
• 1 X Serial ATAIII 6Gb/s
• 3 X Serial ATAII 3Gb/s
Audio
º VIA 1705
?VIA® VT1705 6-channel High Definition audio CODEC
?Compliant with HD audio specification for a whole new
immersive surround sound experience
?3 DACs and 2 ADCs with High-performance ADCs with
100dB SNR, DACs with 100dB SNR
?Low Power Consumption
?Capability for “full rate” BluRay / DVD / HD DVD support.
LAN
º Realtek 8111E Gigabit Fast Ethernet Controller
º (Realtek 8105E 10/100Mbps Fast Ethernet Controller
optional)
USB
º Support by NM70 Express Chipset
• 8 X USB2.0 port(s) Up to 480 Mb/s
Back Panel 4 port(s)
Onboard 4 port(s)
REAR PANEL I/O
º 1 X PS/2 Keyboard & PS/2 mouse connectors
º 1 X Serial port (COM)
º 1 X Audio port (Line Out/Line In/Mic In)
º 1 X HDMI port(s)
º 1 X DVI-I port(s) (optional)
º 1 X D-Sub (VGA) port(s)
º 4 X USB2.0 port(s)
CONNECTORS
& HEADERS
º 1 X 24-pin ATX Power Supply connector
º 1 X 3-pin SYS_FAN connector
º 1 X Front Panel switch/LED header
º 1 X Front panel audio header
º 1 X Onboard Buzzer
º 2 X USB 2.0 header
• Support additional 4 USB ports
º 1 X S/PDIF out header
º 1 X SATA III 6Gb/s connector(s)
º 3 X SATA II 3Gb/s connector(s)
º 1 X CLR_CMOS header
º 1 X Serial port header (COM)
º 1 X Parallel port header (LPT)
º 1 X Chassis intrusion header
º 1 X LVDS connector (optional)
º 1 X LDC header
SYSTEM BIOS
º AMI BIOS with 32 MB SPI Flash ROM
º Over-Clocking
º Multi-Language BIOS
FORM FACTOR
º Mini ITX Form Factor
º 170mm X 170mm
OS Support
º Windows XP 64-bit
º Windows 7 32-bit
º Windows 7 64-bit
º Windows 8 64-bit
Certifications
º CE/FCC Certification
º ErP/EuP Certification
º WHQL Certification
º WHCK Certification
Bundled Software
º ECS Intelligent EZ Utility : eBLU, eDLU, eSF
º Free Bundle: Norton Internet Security ,CyberLink
PowerDVD, CyberLink PowerDirector 9,
Muzee with trial version
